输入通道
48 (40 单声道 + 2 立体声 + 2 返送通道)
Aux 总线
20 (8 单声道 + 6 立体声)
输入
32 麦克风/线路 (XLR/TRS 混合) + 2 立体声线路 (RCA pin)
USB
34x34 USB 音频接口, 通过USB存储设备可进行 2 轨录音
信号延迟
低于 2.6 ms, INPUT to OMNI OUT, Fs=48 kHz
推子
100 mm 马达推子, 精度 = 10-bit, +10 dB to –138 dB, –∞ dB 所有推子
总谐波失真
低于 0.05% 20 Hz–20 kHz @+4 dBu into 600 , INPUT to OMNI OUT, 输入增益=小 (Measured with a –18 dB/octave filter@80 kHz)
频率响应
+0.5, –1.5 dB 20 Hz–20 kHz, refer to +4 dBu output @1kHz, INPUT to OMNI OUT
动态范围
110 dB typ., DA Converter, 107 dB typ., INPUT to OMNI OUT, Input Gain=Min
等效输入噪声
–128 dBu typ., Input Gain=Max. (Measured with an A-Weight filter)
残余输出噪声
–85 dBu, ST 主控 off (Measured with an A-Weight filter)
串扰
–100 dB (Measured with a –30 dB/octave filter@22 kHz), adjacent INPUT/OMNI OUT channels, Input Gain=Min.
